All product info on the page is for reference only,if any changes please in kind prevail.
|
Main CPU
|
MT7628KN
|
|
Memory
|
8MB
|
|
FLASH
|
2MB
|
|
Standard
|
IEEE 802.11n、IEEE 802.11g、IEEE 802.11b
|
|
Transmission rate:
|
802.11b 18dBm±2dBm;
802.11g 17dBm±2dBm;
802.11n 16dBm±2dBm;
|
|
Receive sensitivity
|
802.11b: -90dBm@10% PER
802.11g: -74dBm@10% PER
802.11n: -68dBm@10% PER
|
|
Frequency and Channel
|
2.4GHz channel selection：1-13
|
|
Data rate
|
300Mbps
|
|
Frequency band
|
2.4GHz
|
|
Antenna
|
built in high gain 3dbi Omni antenna
|
|
Hardware Interface
|
One (1) USB2.0
|
|
LED
|
(Power,SYS reuse),SIGNAL
|
|
Button
|
Reset Button
|
|
Consumption
|
< 5W
|
