All product info on the page is for reference only,if any changes please in kind prevail.
|
Specification
|
|
|
Interface type:
|
USB 2.0/1.1
|
|
Frequency Range:
|
2.4~2.4835GHz
|
|
Transmission Rate:
|
11n:270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps;
65/58.5/52/39/26/19.5/13/6.5Mbps
11g:54/48/36/24/18/12/9/6M(Auto Adaptation)
11b:11/5.5/2/1M(Auto Adaption)
|
|
Working Channel:
|
1~13
|
|
Modulation type:
|
OFDM/CCK/16-QAM/64-QAM
|
|
Receiving Sensitivity:
|
270M:-68dBm@10%PER;
130M:-68dBm@10%PER;
108M:-68dBm@10%PER;
54M:-68dBm@10%PER
11M:-85dBm@8%PER;
6M:-88dBm@10%PER
1M:-90dBm@8%PER
RF: 20dBm (max)
|
|
System:
|
Windows2000/XP/VISTA/7/8, Linux,MAC,MAX,OSX
|
